Reliance PBN20 20 Amp NEMA 3R PBN Series Non-Metallic Power Inlet Box

Features

• The raintight NEMA 3R PBN Series non-metallic power inlet box is designed for use with the Pro/Tran transfer switches and Panel/Link manual transfer panels and generator-ready load centers.
• This power inlet box must be installed outdoors in an open area where the generator is being used.
• Using one of the three ¾-inch knockouts (one each on the sides and back) the power inlet box can be wired directly to the transfer switch or panel.
• The patented design provides over 100 cubic inches of wiring space and the slide-out base allows easy 360° access to the flanged inlet.

What's in The Box

• Transfer Switch Accessory - PBN20
• Owner's Manual

Warranty

• 30-Day Satisfaction Guaranteed

Specifications

SKU	PBN20
Brand	Reliance
Model Description	Non-metallic Power Inlet Box
Max Generator Running Watts	5000
Max Generator Input	20A at 125/250VAC
Cabinet Type, NEMA	Outdoor, NEMA 3R
Configuration	L14-20
Dimensions (H x W x D)	6.25 x 6.25 x 4.25
